Bermad 2PB / FP2PBL Pressure Reducing Pilot Valves

SKU:
FP-FB-SERIES-PILOT

PRODUCT INFORMATION

Bermad 2PB / FP2PBL Pressure Reducing Pilot Valve

The model #2PB is a direct acting, single seated spring loaded diaphragm pressure reducing pilot valve. It is actuated by a pressure responsive diaphragm, which tends to reach equilibrium with the pre-set and field adjustable spring force. It’s fully balanced poppet design ensures high accuracy and stability. When installed as a Pressure Reducing pilot valve on a BERMAD Water Control or Deluge valve, it automatically controls the main valve to reduce a higher inlet pressure to a lower constant outlet pressure, maintaining the chosen pre-set downstream pressure regardless of fluctuations in the high pressure supply line. The model #2PBL has a larger valve seat, offering a higher flow capacity and therefore a faster regulation response.

FEATURES & BENEFITS

  • Internal pressure sensing
  • Fully balanced poppet for accuracy and stability
  • Wide flow range
  • Available with differential pressure sensing
  • Optional remote sensing

TECHINCAL DATA

General Purpose, Model BE270-A-17

  • Pressure Rating: 28 bar (400 psi)
  • Working Temperature: Water up to 80˚C (180˚F)
  • 2PB Flow Factor: Kv 0.46 (Cv 0.54)
  • 2PBL Flow Factor: Kv 0.96 (Cv 1.13)

LITERATURE

Bermad 2PB / FP2PBL Pressure Reducing Pilot Valve Bermad 2PB / FP2PBL Pressure Reducing Pilot Valve Brochure
