PRODUCT INFORMATION

Bermad WW772-U – Flow Control and Pressure Reducing Valve

The Model 772-U Flow Control and Pressure Reducing Valve is a hydraulically operated, diaphragm actuated control valve with two independent functions. It maintains both pre-set maximum flow and it reduces higher upstream pressure to lower constant downstream pressure, regardless of varying demand or upstream pressure.

Controlling over demand & pressure

• Balancing flow via parallel pressure reducing valves
• Controlling pipeline fill rate
• Pump cavitation & system over pressure protection
• Compensating during groundwater drawdown

FEATURES & BENEFITS

• Line pressure driven – Independent operation
• Hydraulic flow sensor (upstream installation)
  • No moving parts
  • No electronic components
  • No need for flow straightening
• In-line serviceable – Easy maintenance
• Double chamber design
  • Moderated valve reaction
  • Protected diaphragm
• Flexible design – Easy addition of features
• Variety of accessories – Perfect mission matching
• "Y" or angle, wide body – Minimized pressure loss
• Semi-straight flow – Non-turbulent flow
• Stainless Steel raised seat – Cavitation damage resistant
• Obstacle free, full bore – Uncompromising reliability
• V-Port Throttling Plug – Low flow stability

TECHNICAL DATA

• Solenoid control – 772-55-U
• Check feature – 772-20-U
• Solenoid control & check feature – 772-25-U
• Downstream over pressure guard – 772-48-U

LITERATURE

Bermad WW772-U – Flow Control and Pressure Reducing Valve Brochure
