PRODUCT INFORMATION
Clack WS1.5PEI Specialist Water Control Valve 1.5" Inlet/Outlet
FEATURES & BENEFITS
- 1.5" top mount control valve suited for mid-size commercial/industrial applications
- Epoxy coated lead free brass valve body*
- Economical optional meter
- Service flow rate of 265 lpm (15.9 m³/h) (70 gpm), backwash 197 lpm (11.8 m³/h) (52 gpm)
- Solid state microprocessor with easy access front panel settings
- Front panel display for time of day, days until next regeneration, volume remaining, current flow rate and total volume used (Totalizer)
- Four methods to initiate regeneration; meter immediate, meter delayed, time clock delayed or pressure differential
- Optional double backwash feature offers optimum regeneration, cleaning ability and efficiency
- Fully adjustable cycle times with 6-cycle control delivers controlled backwash, downflow brining or upflow brining, slow rinse, second backwash, fast rinse, refill and downflow service
- Coin Cell Lithium battery back-up with a 8 hour carry over
- 12-volt output AC Adapter provides safe and easy installation
- Post treated water regenerant refill
- 24 hour clock
- Patented one piece expanding seal spacer stack assembly U.S. Patent 6,402,944
- Patented linearly reciprocating piston operation U.S. Patent 6,444,127
- Reliable and proven DC drive
TECHNICAL DATA
WATER SPECIALIST 1.5" EI CONTROL SPECIFICATIONS
| Inlet/Outlet Fittings |
1.5” Male BSPT or NPT |
| Cycles |
Up to 6 |
| Valve Material |
Glass filled composite |
| Regeneration |
Downflow / Upflow |
FLOW RATE
| Service @ 1 bar/15 psi drop (includes meter) |
227 lpm (13.6 m3 /h) (60 gpm) |
| Backwash @ 1.7/25 psi bar drop |
163 lpm (9.8 m3 /h) (43 gpm) |
OPERATING PRESSURES
| Minimum/Maximum |
1.4 - 8.6 bar (20 - 125 psi) |
OPERATING TEMPERATURES
| Minimum/Maximum |
4º - 43º C (40º - 110º F |
DIMENSIONS & WEIGHT
| Distributor Pilot -Valve bodies with 1.5" Female BSPT Inlet & Outlet -Valve bodies with 1.5" Female NPT Inlet & Outlet |
50 mm OD -50 mm OD -1.90” OD (1.5" NPS) |
| Drain Line |
1” Male BSPT Elbow |
| Brine Line |
½” OD Poly Tube Compression |
| Mounting Base |
4" - 8 UN |
| Height From Top Of Tank | 273.05 mm (10.75”) |
| Weight |
4.1 kg (9 lbs.) |
ELECTRICAL SPECIFICATIONS
| Supply Voltage |
200VAC to 240VAC |
| Supply Frequency |
50/60 Hz |
| Output Voltage |
15VDC |
| Output Current |
500 mA |
TANK APPLICATIONS
| Water Softener |
12” - 24" Diameter |
| Water Filter (2) |
12” - 24" Diameter |
CYCLES OF OPERATION (SOFTENER / FILTER downflow)
| 1. Backwash 1st |
1-95 |
| 2.Regenerate Draw/Slow Rinse (downflow) |
1-180 |
| 3.Backwash 2nd (upflow) |
1-95 |
| 4.Fast Rinse (downflow) |
1-95 |
| 5.Regenerant Refill | 0.1-99.0 or off |
| 6.Service (downflow) |
LITERATURE
 |
Clack WS1.5PEI Specialist Water Control Valve 1.5" Inlet/Outlet Brochure |
