Atlas Filtri 50 Micron Pleated Coarse Sediment Filter 10"

SKU:
ATL-TS10SX50MCR

PRODUCT INFORMATION

50 Micron Pleated Coarse Sediment Filter 10" Std

FEATURES & BENEFITS

SEDIMENT FILTERS

  • Sediment Filters are used to remove particles from water and protect downstream taps etc from clogging
  • Sediment cartridges are resistant to attack by bacteria and chemicals and are suitable for a wide range of applications, including domestic, commercial, and industrial.

CS & TS Pleated Cartridge Range

  • Pleated cartridges are commonly used as primary filtration for sediment as they can be cleaned and reused.
  • The 20 & 25 micron versions are often used as the first in a series of filters, including as the primary filter in UV kits.
  • They have a large surface area to accommodate high flows with a low pressure drop.

TECHNICAL DATA

Brand Atlas Filtri
Product Type Pleated Filters
Flow Rate (L/min) 42
Material Polypropylene/Polyester Fabric
Nominal Micron Rating 50
Min Temp (degrees celsius) 4
Max Temp (degrees celsius) 45
Filter 10" Big



LITERATURE

Atlas Filtri 50 Micron Pleated Coarse Sediment Filter 10 Atlas Filtri 50 Micron Pleated Coarse Sediment Filter 10" Std Brochure
