Bermad 2 – Pressure Reducing Pilot 2 Way



Bermad 2 – Pressure Reducing Pilot 2 Way

This pilot integrates all principal functions of a 2-way control circuit in a single assembly. It is a direct acting valve, actuated by a pressure responsive diaphragm, which tends to reach equilibrium with the set spring force. When used in a pressure reducing circuit, the pilot modulates closed as downstream pressure rises above set point. An integral needle valve acts as an upstream flow restrictor, as well as a closing speed control.


  • Pressure Reducing Valves sizes (Standard model #2)
  • Flow Control Valves (Modified to differential sensing #2-DR)
  • Surge Anticipating Valves as low pressure pilot

(Modified to external pressure sensing #2-R)

  • Surge control closing additional feature 49

(Modified to external pressure sensing #2-R)


  • ֺ Integral needle valve
  • ֺ Internal or external pressure sensing
  • ֺ Differential pressure sensing
  • ֺ Direct pressure gauge installatioN


  • Pressure Rating: 40 bar; 600 psi
  • Working Temperature: Water up to 60°C; 150°F
  • Flow Factor: Kv 1.0; Cv 1.2
  • Valve Size Range: Medium
  • Standard Materials:
  • Body & cover: Brass
  • Elastomers: NBR
  • Internals: Stainless Steel & Brass
  • Spring: Galvanized Steel
  • Optional Materials:
  • Metal Parts: Stainless Steel, Nickel Aluminum Bronze, Hastalloy
  • Elastomers: FPM (Viton®)


Bermad 2 – Pressure Reducing Pilot 2 Way Bermad 2 – Pressure Reducing Pilot 2 Way Brochure
