PRODUCT INFORMATION
Clack 24 & 30" Commercial/Industrial Blow Moulded Brine Tank Series
Clack offers both 24" and 30" round blow molded brine tanks. The introduction of the 30" diameter tank makes it the largest blow molded brine tank for commercial/industrial applications.
FEATURES & BENEFITS
- Like the 24" round tank, the 30" tank is molded of high density polyethylene for exceptional stress and crack resistant properties.
- These tanks are ideal for industrial and commercial use and the 30" tank feature heavy wall thickness for increased durability.
- Injection molded grids are available for both 24" and 30" tanks and use 11⁄2" schedule 40 PVC pipe for leg supports.
- The legs can be cut to any length for easy grid height adjustment. A precut leg kit for the 24" grid is also available, giving it an overall grid height of 101⁄4".
TECHNICAL DATA
| ORDER NUMBER | DESCRIPTION | LIQUID CAPACITY | SALT CAPACITY | HEIGHT W/LID | DIAMETER | SHIPPING WEIGHT | CARTON SIZE | UNITS PER CARTON |
| G22441CB1C00 | 24 x 41 Black Brine Tank | 80 gal./ 303 liters | 700 lbs./ 318 Kg | 42.5 in/ 108 cm | 24.5 in./ 62 cm | 23.5 lbs./ 10.7 Kg | 15 ft.3 | 1 |
| G22450CB1C00 | 24 x 50 Black Brine Tank | 100 gal./ 378 liters | 900 lbs./ 408 Kg | 51.5 in/ 131 cm | 24.5 in./ 62 cm | 27.25 lbs./ 12.4 Kg | 18 ft.3 | 1 |
| G23050CB1C00 | 30 x 50 Black Brine Tank | 150 gal./ 579 liters | 1400 lbs./ 640 Kg | 52.5 in/ 133 cm | 31 in./ 79 cm | 49 lbs./ 22.3 Kg | 30 ft.3 | 1 |
LITERATURE
 |
Clack 24 & 30" Commercial/Industrial Blow Moulded rine Tank Series Brochure |
