PRODUCT INFORMATION
DAB JINOX132M Stainless Steel Self Priming Jet Pump
Suitable for water supply in domestic installations, small-scale agriculture and gardening.
Self-priming centrifugal pump with excellent suction capacity even when there are air bubbles and small particles of sand in the water.
Used especially for supplying water to domestic installations. Ideal for use in small-scale agriculture and gardening, limited industrial services, and wherever self-priming operation is necessary.
FEATURES & BENEFITS
Constructional features of the pump
Cast iron pump body and motor support.
Motor support in die-cast aluminium for Jet 62-82-102-112-92-132.
Technopolymer impeller, diffuser, Venturi tube and sand guard.
Stainless steel pressure discs.
Carbon/ceramic mechanical seal.
TECHNICAL DATA
| Brand | DAB Pumps |
| Product Type |
Single Stage Jet Pump |
| Suitable For |
Clean Water |
| Bar |
4.8 Bar |
| Approval |
Approved For Drinking Water |
| Flow Range Category |
a. 0 - 99 L/min |
| Flow Rate (L/min) |
80 L/min |
| Hp |
1.36 Hp |
| kPa | 486 kPa |
| Kilo Watts |
1 kW |
| Head Range Category |
c. 40 - 59 m |
| Max Head (m) | 61 m |
| Port Size Inlet |
1" BSPF inlet |
| Port Size Outlet |
1" BSPM outlet |
| Powered | Electric |
| Volts |
240V |
| Warranty (months) |
24 Months |
| Watts |
1000 W |
DRAWINGS
 |
 |
LITERATURE
 |
DAB JINOX132M Stainless Steel Self Priming Jet Pump Brochure |
