PRODUCT INFORMATION

Bermad Analogue Valve Position Transmitter

This Analog Valve Position Transmitter assembly is an accessory which enables remote signaling upon the rate of opening of the BERMAD control valves. It is equipped with an ultrasonic, easy to set, sensor that measures, without contact, the movement of the valve position indicator.

This Analog Valve Position Transmitter is suitable for

BERMAD 700, 800 and 400 Series

FEATURES & BENEFITS

• Simple setting
• Easy on-site assembly
• Corrosion resistant construction
• Vibration resistant technology
• Easy programming and calibration

TECHNICAL DATA

• Operating Voltage: 20-30V DC
• Analog output: 4-20mA
• Protection: IP67
• Accuracy: ≤ 2%
• Control: Teach-in push-button
• Temperature: -25 to +70°C; -13 to +158°F
• Blind zone: 20mm
• Operating range: 150mm
• Reproducibility: 0.15 ±
• Indicators: LED green (operation)
• LED yellow (state of output)

LITERATURE

Bermad Analogue Valve Position Transmitter Brochure
