PRODUCT INFORMATION
Bermad IR-C50-IP Irrigation Air Release Valve with inflow protection
BERMAD C50 is a high quality combination air valve for a variety of sewage and wastewater networks and operating conditions. It evacuates air during pipeline filling, allows efficient release of air and gas pockets from pressurized pipes, and enables large volume air intake in the event of network draining. The elongated body and lower float prevent the fluid to be in contact with the upper mechanism. With its advanced aerodynamic design, double orifice and Surge Protection device (optional), this valve provides excellent protection against air and gas accumulation and vacuum formation with improved sealing under low pressure conditions
Specifically designed for irrigation applications.
APPLICATIONS
- Pumping stations: Air relief and vacuum prevention.
- ֺNon Clean Water pipelines: Protection against air and gas accumulation and vacuum formation at elevations, slope change points and at road/ river crossings.
- ֺ Wastewater Treatment plants: Air relief, protection against air and gas accumulation and vacuum formation.
FEATURES & BENEFITS
- ֺStraight flow body with large diameter automatic orifice: Higher than usual air flow.
- ֺAerodynamic, full-body kinetic shield: Prevents premature closing without disturbing air intake or discharge.
- ֺDynamic Sealing: Prevents leakage under low pressure conditions (0.8 psi; 0.05 bar).
- ֺElongated body design: Prevents solids from making contact with valve’s operating parts.
- ֺCompact, simple and reliable structure with fully corrosion-resistant internal parts: Lower maintenance and increased life span.
- ֺTwo service ports: Enabling back flushing and drainage.
- ֺThreaded Side outlet (2"; DN50) for connection of Surge
- Protection (SP) or Inflow prevention (IP) devices.
- ֺFactory approval and Quality Control: Performance and specification tested and measured with specialized testbench, including vacuum pressure conditions
TECHINCAL DATA
- Pressure Rating: 150 psi; ISO PN10 (C50-P), 230 psi; ISO PN16
- (C50-C, C50-J, C50-G, C50-N)
- ֺ Minimum operating pressure: 0.8 psi; 0.05 bar
- ֺ Maximum operating pressure: 150 psi; 10 bar (C50-P), 230 psi;
- 16 bar (C50-C, C50-J, C50-G, C50-N)
- ֺ Media and operating temperature: Water, 33-140°F; 1-60°c
LITERATURE
 |
Bermad IR-C50-IP Irrigation Air Release Valve Brochure |
