PRODUCT INFORMATION
DAB K80-300T Centrifugal 415V Twin Impeller Pump 400L/Min 415V
Ideal for rivers, tanks, dams and water transfer applications.
APPLICATIONS
Twin Impeller Centrifugal PumpsIdeal for rivers, tanks, dams and water transfer applications.
FEATURES & BENEFITS
CONSTRUCTION FEATURES OF THE PUMP.
Pump body and motor support in cast iron.
Technopolymer or cast iron impeller, as per the Technical Data table.
Carbon/ceramic mechanical seal.
CONSTRUCTION OF THE MOTOR
Closed asynchronous type, external ventilation cooling.
Rotor running on ball bearings, oversized to ensure low noise and durability.
Standard built-in thermo-amperometric protection. Capacitor permanently on single phase versions.
For the protection of the three-phase motor, we recommend the use of remote overload cut-outs, in compliance with the current local regulations.
Construction account to CEI 2-3
IE2 motors as standard, from 0,75 kW to 55 kW-IE3 >_7,5 kW.
TECHNICAL DATA
| Brand | DAB Pumps |
| Product Type |
Twin Impeller Cast Iron Pump |
| Suitable For |
Water Transfer |
| Bar |
9.5 Bar |
| Flow Range Category |
e. 400 - 499 L/min |
| Flow Rate (L/min) |
400 L/min |
| Hp |
10 Hp |
| kPa | 962 kPa |
| Kilo Watts |
7.5kW |
| Casing Material | Cast Iron |
| Head Range Category |
c. 60 - 99 m |
| Max Head (m) | 95 m |
| Port Size Inlet |
2" BSPF inlet |
| Port Size Outlet |
1 1/4" BSPF outlet |
| Powered | Electric |
| Volts |
415 V |
| Warranty (months) |
24 Months |
| Watts |
7500 W |
DRAWINGS
 |
 |
LITERATURE
 |
DAB K80-300T Centrifugal 415V Twin Impeller Pump 400L/Min 415V Brochure |
