Bermad HRV Hydraulic Relay Valve Model 50
This 2-Way, single chamber hydraulic relay valve is a hydraulically operated, diaphragm actuated control valve that either opens fully or shuts off in response to pressure applied to its control chamber.
TECHNICAL DATA
- Pressure rating: 25 bar (350 psi)
- Working temperature: Water up to 80 ̊C (180 ̊F)
- Flow factor: Kv 1.3 (Cv 1.5)
- Standard materials:
- Body & cover: Brass
- Elastomers: NBR
- Internals: Stainless Steel & Brass
- Optional materials:
- Metal parts: Stainless Steel, Nickel Aluminum Bronze, Hastalloy Elastomers: FPM (Viton®) Model 50
- The information herein is subject to change without notice. BERMAD shall not be held liable for any errors. All rights reserved. © Copyright by BERMAD. PCXWE0C 05 3/8” NPT
