PRODUCT INFORMATION
DAB 82MP-8V Cast Iron Spear Point Pump With Pressure Switch & Tank
Self Priming Cast Iron Jet Pressure Pumps
Applications
- Domestic installations where a suction lift is required
- Pressure boosting, irrigation and wash down
- Designed for pumping from tanks, rivers, and dams.
Reflex Tanks are highly constructed pressure tanks suitable for most domestic and commercial applications.
- Nominal volume: 18L
- Nominal Draw-off: 6L
- Continuous max. temp 70°C
- Continuous max. pressure: 10 Bar
- Pre-charge: 4 Bar (58PSI)
- Diameter: 280 mm
- Height: 407mm
- Net Weight: 3.2Kg
- System Connection: GI
- Colour: BLUE RAL 5007
FEATURES & BENEFITS
Constructional features of the pump
Pump: Cast iron pump body and motor support. Technopolymer impeller and diffuser.
Stainless steel adjustment ring. Carbon/ceramic mechanical seal.
Ejector: Cast iron body. Technopolymer A Venturi tube and brass nozzle.
The ejector is available in three models (E20 - E25 - E30) to be chosen according to performance requirements.
Constructional features of the motor
Asynchronous motor, closed and cooled with external ventilation.
Rotor mounted on oversized greased sealed-for-life ball bearings.
Built-in thermal and current overload protection and a capacitor permanently in circuit in the single-phase version.
For the protection of the three-phase motor, it is advisable to use a suitable overload protection complying with the regulations in force.
Manufactured according to CEI 61-69 standards (EN 60335-2-41).
Motor protection: IP 44
Terminal box protection: IP 55
Insulation class: F
Operating range: up to 4.3 m3/h.
- Liquid quality requirements: clean, free from solids or abrasive substances, not viscous, not aggressive, not crystallized, chemically neutral, close to the characteristics of water.
- Liquid temperature range: from 0°C to +35°C for domestic use (EN 60335-2-41)
from 0°C to +40°C for other uses - Maximum ambient temperature: +40°C
- Maximum operating pressure: DP 82 - DP 102 6 bar (600 kPa), DP 151 - DP 251 8 bar (800 kPa)
- Installation: fixed in a horizontal position
- DAB 300M Cast Iron Jet Pump Shallow Well
- 240V single phase TEFC motor with in-built auto reset thermal overload to prevent pump from damage
TECHNICAL DATA
| Brand |
DAB Pumps |
| Suitable For |
Clean Water |
| Bar |
4.7 Bar |
| Approval | Approved For Drinking Water |
| Flow Range Category |
a. 0 - 99 L/min |
| Flow Rate (L/min) |
60 L/min |
| Hp |
0.8 Hp |
| Kilo Watts |
0.6 kW |
| Head Range Category | b. 40 - 59 m |
| Max Head (m) |
47 m |
| Port Size Inlet | 1" BSPF inlet |
| Port Size Outlet |
1" BSPM outlet |
| Powered |
Electric |
| Taps |
6 Taps |
| Warranty (months) | 24 Months |
| Volts |
240 V |
| Watts |
600 W |
DRAWINGS
 |
 |
LITERATURE
 |
DAB 82MP-8V Cast Iron Spear Point Pump With Pressure Switch & Tank Brochure |
