PRODUCT INFORMATION

SV280-V Heavy Duty Solids Pump

The SV280-V Heavy Duty Solids Pump is a high velocity, heavy duty solids pump, capable of capturing high density slurries via a strong 25”Hg vacuum combined with high velocity airflows.

The SV280-V Heavy Duty Solids Pump can handle solids to 80% of the employed hose diameter and will transfer up to 40 m3/hr @SG1.0(132USGPM) depending on the materials and distances involved.

APPLICATIONS

• Capture and transfer of drill cuttings
• Sump cleaning and desilting
• Tank bottoms and sludge extraction
• Tailings transfer or dewatering
• OBM transfer and pit cleaning
• Bentonite and sand transfer

FEATURES & BENEFITS

The SV280-V Heavy Duty Solids Pump has no moving components that come in contact with the material being pumped and can pass rags, bolts and many other items that would render a standard impeller pump inoperable.

• ATEX Zone 2/CE conformity
• 100% compressed air operation
• Intrinsically safe
• Manual or fully automatic operation
• Robust construction and low wear characteristics
• High vacuum and high airflow
• Delivers up to 1000 metres (3280ft) horizontally and 35 metres (115ft) vertically
• High solids content transfer

TECHNICAL DATA

• Suction inlet 100mm (4”), plus 4” Gravity feed option
• Discharge outlet 100mm (4”)
• Gravity Feed (4″)
• Handles solids to 70mm (3”

LITERATURE

SV280-V Heavy Duty Solids Pump Brochure
